Disco PA System
This 1.6kW system is designed for weddings, private parties and fund-raising or other social events. It combines microphone mobility and high intelligibility (for announcements, speeches, or DJ commentary) with the extended bass response needed for high quality disco or dance music. It is adequate for events with between about 50 (teen drum 'n' bass) and 250 (wedding party) guests, and can be supplemented with additional loudspeakers where higher volume is required.
Spare audio inputs on the mixer allow for iPods, laptops or other audio sources (cables for this are included).
A range of supplementary disco equipment is available (including cross-fade mixers, vinyl decks or CDJs), as well as disco effects lighting and DJ monitors.
Venue Suitability
- Small to medium-sized venues (up to about 250 people), hotels and village halls;
- Marquees up to about 750 square metres.
Features
- High output and deep bass;
- Premium audio quality at all volumes;
- Multiple inputs for additional sound sources;
- Doubles as a speech/announcement system;
- Installation and configuration by an experienced audio professional;
- Supplementary equipment available.
Applications
- Discos and private parties (e.g. weddings, birthdays, Christmas parties);
- Dinner-dances and fund-raising events;
- Can be used with additional equipment for live music (e.g. wedding band and iPod disco).
System Details
Mixer
Soundcraft EFX-12
The EFX-12 is an excellent small-frame mixer. With 12 mono + 2 stereo channels it has all the facilities and controls you need, but is simple to use as a simple level control if that is all you need to do.
Processing and Effects
dbx 231 Graphic Equaliser (2U)
If you need to deal with feedback, or simply to change the overall tonal balance, the included dbx 231 - with 2 × 31-bands, +/-6 or +/-12dB, and high-pass and bypass functions - makes it easy to do.
Effects are not generally requested with this system, but the EFX-12 has two configurable channels of Lexicon effects if they are required.
Loudspeaker System
The Disco System is supplied with a three-way bi-amplified Martin Audio loudspeaker system, comprising:
Martin Audio F10 mid/high loudspeakers
The F10, from Martin Audio's acclaimed Blackline range, provides a clear and natural mid/high-frequency complement to the S15's deep and powerful bass.
Martin Audio S15 bass speakers
This is the way bass is supposed to sound!
dbx Driverack PA system controller
This fully-programmable digital loudspeaker-management unit ensures that the amplifiers and loudspeaker system deliver optimum performance.
QSC PLX 1804 amplifiers
One for the bass speakers, another for the tops.
Bi-amplification provides substantial audio improvement compared to passive loudspeaker systems.
Each QSC PLX1804 amplifier provides 2 × 550 Watts (FTC, 20Hz - 20kHz, 0.05% THD) with the loudspeakers supplied: enough to deliver a full and powerful sound without distortion.
Input Equipment
- Delivery, set-up, take-down & collection are included without extra charge anywhere within a 15 mile radius of Stroud (which includes most of Cheltenham and Gloucester, and much of the surrounding area). Extra delivery charges may apply over greater distances (see our prices page for details).
